Mercusys AC10
AC1200 Wireless Dual Band Router – 300 Mbps at 2.4 GHz + 867 Mbps at 5 GHz
2× 10/100 Mbps LAN Ports + 1× 10/100 Mbps WAN Port
4× Fixed External Antennas,
Beamforming, MU-MIMO, Access Point Mode
- Description
- Additional information
- Specification
Description
Mercusys AC10
- High-Speed Wi-Fi – Stream with fast and stable connections, reaching speeds up to 1167 Mbps (300 Mbps on the 2.4 GHz band and 867 Mbps on the 5 GHz band)
- 4 High-Gain External Antennas – Receive strong Wi-Fi signals in every corner of your home
- Easy Installation – Set up in minutes guided by an intuitive web UI
- Active Parental Controls – Protect your family by setting appropriate access policies for responsible, safe internet use
- Multi-Mode — Access Point Mode, Range Extender Mode, and Router Mode supported to satisfy all application scenarios
- IPTV and IPv6 Supported
View more in Official Website
Additional information
| Brand | Mercusys |
|---|---|
| Model | AC10 |
- Wireless
- Wireless Standards
- IEEE 802.11ac/n/a 5 GHz, IEEE 802.11b/g/n 2.4 GHz
- Frequency
- 2.4 GHz, 5 GHz
- WiFi Speeds
- Up to 300 Mbps on 2.4 GHz, 867 Mbps on 5 GHz
- Reception Sensitivity
- 11g 6Mbps: -96dBm
11g 54Mbps: -78dBm
11n HT40 MCS7: -74dBm
11n HT20 MCS7: -71dBm
11a 6Mbps: -97dBm
11a 54Mbps: -79dBm
11ac VHT20 MCS8: -74dBm
11ac VHT40 MCS9: -70dBm
11ac VHT80 MCS9: -65dBm - Transmission Power
- 2.4 GHz < 20dBm (EIRP)
5 GHz < 23dBm (EIRP) - Wireless Security
- WEP, WPA / WPA2, WPA-PSK / WPA2-PSK
- Wireless Functions
- Enable/Disable Wireless Radio, WMM
- Software
- Operation Modes
- Router Mode, Access Point Mode
- WAN Type
- Dynamic IP/Static IP/PPPoE/L2TP/PPTP
- Management
- Access Control, Local Management, Remote Management
- DHCP
- Server, DHCP Client List
- NAT Forwarding
- Port Forwarding, Port Triggering, UPnP, DMZ
- Firewall Security
- SPI Firewall, IP and MAC Address Binding
- Guest Network
- 2.4 GHz Guest Network, 5 GHz Guest Network
- Hardware
- Dimensions
- 4.5 × 3.7 × 1.0 in (114 × 94 × 26 mm)
- Interfaces
- 1× 10/100 Mbps WAN Port
2× 10/100 Mbps LAN Ports - Button
- Reset/WPS Button
- External Power Supply
- 9V/0.85A
- Antenna Type
- 4× 5 dBi Fixed Omni-Directional Antennas
- Others
- Package Contents
- AC1200 Wireless Dual Band Router AC10
Power Adapter
Quick Installation Guide
RJ45 Ethernet Cable - Environment
- Operating Temperature: 0°C~40°C (32°F~104°F)
Operating Humidity: 10%~90% Non-Condensing
Storage Humidity: 5%~90% Non-Condensing
