Описание
- 93.6Ah/10.95V Automotive-Grade Lithium Battery (31.2Ah Per Lithium Battery)
- Remote Management and Maintenance via the VIG app or VIGI Cloud VMS
- Indendent Protection Circuit Ensures Battery Safety and Uninterrupted Device Operation
- Intelligent Auxiliary Heating Technology Ensures Optimal Battery Performance in Extreme Cold Weather
- Maximum Power Point Tracking (MPPT) Charging Controller Increases Charging Efficiency by 20%*
- Remaining Capacity > 70%** after 500 Cycles
- IP66 Weatherproof
Посмотреть больше в официальный сайт
Детали
| Бренд | ВИГИ |
|---|
| Battery | |
|---|---|
| Тип | Lithium |
| Intelligent Auxiliary Heat | Да |
| Battery Capacity | 93.6Ah(Max),31.2Ah(Per Lithium Battery) |
| Voltage | 10.95 V |
| Max. Output Voltage | 12.6 V |
| Life | More than 500 cycles† |
| Dimension | • 9.4×2.9×2.8 in (240×74×72 mm) (Per Lithium Battery) |
| Charging Condition | • 0°C~45°C • -30°C~45°C (With intelligent auxiliary heating) |
| Discharging Condition | • -20°C~60°C • -30°C~60°C (With intelligent auxiliary heating) |
| HARDWARE | |
|---|---|
| Интерфейс | • 1× Three-pin Female Connector For Connecting The Controller • 1× Three-pin Male Connector For Connecting The Modular Battery • 2× Four-pin Female Connectors For Connecting The Solar Panel • 1× 10/100 Mbps RJ45 • 3× 5.5mm DC Power Plugs (#1, #2: 9V-12.6 VDC/2A, #3: 12 VDC/2A) |
| Indicator LED | • Quantity: 6 (1× SYS Indicator, 1× LAN Indicator, 1× PV Indicator, 3× BAT Indicator) • Color: Blue |
| ФУНКЦИИ ПРОГРАММНОГО ОБЕСПЕЧЕНИЯ | |
|---|---|
| Load Control | Да |
| High and Low Temperature Protection | Да |
| Overdischarge Protection | Да |
| Power Consumption Statistics | Да |
| Displays Real-time Load Status | Да |
| Battery Level Display | Да |
| Time Zone Selection | Да |
| Schedule Saving | Да |
| Firmware Remote Update | Да |
| Remote Reboot | Да |
| Local LAN Management | Да |
| Smart Charging Control | -30°C~5°C |
| Account Management | Да |
| Remote Reset | Да |
| Remote Message Push | Да |
| ДРУГИЕ | |
|---|---|
| Сертификация | • CB, PSE (Battery) • CE, FCC, VCCI, IC, IP66 |
| Содержимое упаковки | • VIGI PS90 • Руководство по установке • Водонепроницаемые кабельные крепления • Монтажные принадлежности • Extension Cable • Box Key |
| Box Dimensions (W X D X H) | 18.9×16.8×6.4 in (481*426*163 mm) |
| Weight | • Product Weight: 16.5 kg • Package Weight: 24 kg |
| Среда | • Operating Temperature: -30°C-60°C (With intelligent auxiliary heating) • Operating Humidity: 10%~90%RH, Non-condensing |
